ITC T-7707 50W IP Network Wall Mount Speaker Specs:
Professional integration wall-mounted design, the speaker case is subject to the sound resonance principle design concept, with an elegant and beautiful appearance. Adopt embedded computer and DSP audio processing technology, and high-speed industrial SCM system chips, to ensure the start-up time is less than 1 second. Built-in one network hardware audio decoding module, it supports TCP/IP, and UDP, to realize the network transfer audio signal of 16 CD class perfect sound quality. Build-in 2-channel digital amplifier 2 x 20W, 1 channel to connect the main speaker, the other connect assistant speaker to fulfill smooth and strong sound quality, with the network volume setting. With 1 AUX input, independent volume potentiometer control, support offline local. paging function. Support mute volume preset and background music mix output preset
Build-in 2 priority settings:
1) Network voice alarm has higher priority than AUX and Network BGM
2) AUX has higher priority than Network BGM
* Compatible with Router, PABX, bridge gateway, modem, internet, 2G, 3G, 4G, multicast, unicast, and any other network construction.
* Digital products with easy expansion, without geographical restrictions, no need to increase management equipment on the machine room, using a common network from the design concept of line construction for easy installation. It supports remote hardware updates of the terminal, no need go to upgrade at the local site, to reduce maintenance burdens and make more simple operation.
|Network Interface||standard RJ45 input|
|Protocol Support||TCP/IP, UDP|
|Audio Mode||16-bit CD quality|
|AUX Input Sensitivity||350mV (unbalanced)|
|Frequency Response||80Hz~16KHz +1/-3dB|
|Circuit Protection||Overload, short circuit protection|
|Operating Humidity||20%~80% relative humidity, non-condensing|
|Operating Power Supply||~190-240V 50-60Hz|
